LiFePO4 battery golf cart battery lead acid battery 12V 200ah replacement lithium battery., lithium battery lifepo4 battery lithium ion battery

Model number LiFePO4-12.8v 200ah-#5643
Mark Junlee
Origin China
small orders Accepted

Key Specs/ Special Features:

  • :Longer life:
    Offers up to 20 times longer life and five times longer float/schedule life than lead-acid battery,
    helping to minimize replacement cost and reduce total cost of ownership
    Lighter weight :
    Approximately 40% the weight of a comparable lead-acid battery. A “drop in” replacement for lead acid batteries
    higher power : Provides twice the power of lead-acid battery, even high discharge rate, while maintaining high energy capacity
    Wider temperature range: -20℃~60℃
    Superior Security:
    Lithium iron phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation

Longer life cycle :

Offers up to 20 times longer life and five times longer float/schedule life than lead-acid battery,
helping to minimize replacement cost and reduce total cost of ownership

Lighter weight:

Approximately 40% the weight of a comparable lead-acid battery. A “drop in” replacement for lead acid batteries

LiFePO4 Battery 12V 200ah Golf Cart Battery Lead Acid Battery Replacement lithium battery.  supplier

Higher power:

Delivers twice the power of lead acid battery, even high discharge rate, while maintaining high energy capacity
Wider temperature range: -20℃~60℃

Superior Security:

Lithium iron phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging
or short circuit situation

LiFePO4 Battery 12V 200ah Golf Cart Battery Lead Acid Battery Replacement lithium battery.

Lighter weight:
Approximately 40% the weight of a comparable lead-acid battery. A “drop in” replacement for lead acid batteries
Higher Power: Delivers twice the power of lead acid battery, even high discharge rate, while maintaining high energy capacity
Wider temperature range: -20℃~60℃
Superior Security:
Lithium iron phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation

specification

Electric

Characteristics

Nominal voltage 12.8V
Nominal capacity 200Ah (C5.25℃)
Energy 2560Wh
Internal resistance ≤150mΩ
Life cycle ≥4000cycles 1C 100% DOD
Self-discharge month
Charging efficiency 100% 0.2C
Dischar’s Efficiency 96-99% 0.5C
Standard fees Loading mode 14.8±0.2V
Load cut-off voltage Charge from 0.2 C to 14.8 V, then charge from 14.8 V to 0.02 C cu
Charging current 80A
Max charge current 150A
direct current 10A
standard discharge Max pulse current 450A(
Discharge cut-off voltage 10V
Continuous discharge current 150A
Environment Storage temperature 0℃ to 40℃ (32F to 113F) 60±25% Relative Hum
Charging temperature 0℃ to 45℃ (32F to 113F) 60±25% relative humidity
Discharge temperature _20℃ to 60℃ (32F to 113F) 60±25% relative humidity
Mechanical Cell & Method 3.2V 25AH-4S8
Plastic box abs
Dimensions 522*240*218mm
Weight 26.7kg
Terminal m8
Protocol No

Product certificates

Certificate standard THIS
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108053964C
Date of issue 2021/08/04
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/04
Certificate standard THIS
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108053965C
Date of issue 2021/08/04
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/04
Certificate standard THIS
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108164218C
Date of issue 2021/08/04
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/04
Certificate standard TR
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108164218E
Date of issue 2021/08/12
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/12
Certificate standard TR
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108053964E
Date of issue 2021/08/12
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/12
Certificate standard TR
Certificate Image

Click on the image to see a larger one

Certificate number ZKT-2108053965E
Date of issue 2021/08/12
Issued by Shenzhen ZKT Technology Co., Ltd
Expiration date 2025/08/12

To note: Not all certificate agents offer online search, and some have a time limit for issuing new certificates. If you can’t find a certificate online, contact the certifying agency or provider for further verification.

Delivery Information

FOB port Shenzhen
Lead time 15–20 days
Weight per unit 33.0 kilograms
Dimensions per unit 52.2 x 24.0 x 21.8 centimeters
US HTS code 8507.60.00 90
Units per export carton 1.0
Export Carton Dimensions 52.5 x 24.3 x 22.1 centimeters
export carton weight 2 kilograms

Main export markets

– Central/South America

– North America

– Western Europe

Download more information about this product
